STM32F302xx/STM32F303xx
Electrical characteristics
Typical current consumption
The MCU is placed under the following conditions:
●
●
●
V
= V
= 3.3 V
DDA
DD
All I/O pins available on each package are in analog input configuration
The Flash access time is adjusted to f frequency (0 wait states from 0 to 24 MHz,
HCLK
1 wait state from 24 to 48 MHz and 2 wait states from 48 MHz to 72 MHz), and Flash
prefetch is ON
●
●
●
When the peripherals are enabled, f
= f
, f
= f
APB1
AHB/2 APB2 AHB
PLL is used for frequencies greater than 8 MHz
AHB prescaler of 2, 4, 8,16 and 64 is used for the frequencies 4 MHz, 2 MHz, 1 MHz,
500 kHz and 125 kHz respectively.
Table 33. Typical current consumption in Run mode, code with data processing running from
Flash
Typ
Symbol
Parameter
Conditions
fHCLK
Unit
Peripherals
enabled
Peripherals
disabled
72 MHz
64 MHz
48 MHz
32 MHz
24 MHz
16 MHz
8 MHz
61.3
54.8
41.9
28.5
21.8
14.9
7.7
28.0
25.4
19.3
13.3
10.4
7.2
Supply current in
Run mode from
VDD supply
IDD
mA
3.9
4 MHz
4.5
2.5
2 MHz
2.8
1.7
1 MHz
1.9
1.3
500 kHz
125 kHz
72 MHz
64 MHz
48 MHz
32 MHz
24 MHz
16 MHz
8 MHz
1.4
1.1
Running from HSE
crystal clock 8 MHz,
code executing from
Flash
1.1
0.9
240.3
210.9
155.8
105.7
82.1
58.8
2.4
239.5
210.3
155.6
105.6
82.0
58.8
2.4
Supply current in
Run mode from
VDDA supply
(1) (2)
IDDA
µA
4 MHz
2.4
2.4
2 MHz
2.4
2.4
1 MHz
2.4
2.4
500 kHz
125 kHz
2.4
2.4
2.4
2.4
1. VDDA monitoring is ON.
Doc ID 023353 Rev 5
67/133
