A d v a n c e I n f o r m a t i o n
AC Characteristics
555 for program
2AA for erase
PA for program
SA for sector erase
555 for chip erase
Data# Polling
Addresses
PA
tWC
tWH
tAS
tAH
WE#
OE#
tGHEL
tWHWH1 or 2
tCP
CE#
Data
tWS
tCPH
tDS
tBUSY
tDH
DQ7#
DOUT
tRH
A0 for program
55 for erase
PD for program
30 for sector erase
10 for chip erase
RESET#
RY/BY#
Notes:
1. Figure indicates last two bus cycles of a program or erase operation.
2. PA = program address, SA = sector address, PD = program data.
3. DQ7# is the complement of the data written to the device. D
4. Waveforms are for the word mode.
is the data written to the device.
OUT
Figure 20. Alternate CE# Controlled Write (Erase/Program)
Operation Timings
May 13, 2004 27631A4
S29GLxxxN MirrorBitTM Flash Family
103
