2. The host initiates an I/O read cycle to the selected EPP register.
3. Chip asserts nDATASTB or nADDRSTRB indicating that PData bus is tri-stated, PDIR is set and the
nWRITE signal is valid.
4. If nWAIT is asserted, the chip inserts wait states into the I/O read cycle until the peripheral deasserts
nWAIT or a time-out occurs.
5. The Peripheral drives PData bus valid.
6. The Peripheral deasserts nWAIT, indicating that PData is valid and the chip may begin the
termination phase of the cycle.
7. The chip drives the final sync and deasserts nDATASTB or nADDRSTRB.
8. Peripheral tri-states the PData bus.
9. Chip may modify nWRITE, PDIR and nPDATA in preparation of the next cycle.
Table 40 - EPP Pin Descriptions
EPP
SIGNAL
nWRITE
PD<0:7>
INTR
EPP NAME
TYPE
EPP DESCRIPTION
This signal is active low. It denotes a write operation.
Bi-directional EPP byte wide address and data bus.
This signal is active high and positive edge triggered. (Pass
through with no inversion, Same as SPP).
This signal is active low. It is driven inactive as a positive
acknowledgement from the device that the transfer of data is
completed. It is driven active as an indication that the device is
ready for the next transfer.
nWrite
O
I/O
I
Address/Data
Interrupt
WAIT
nWait
I
DATASTB nData Strobe
RESET nReset
O
O
O
This signal is active low. It is used to denote data read or write
operation.
This signal is active low. When driven active, the EPP device
is reset to its initial operational mode.
ADDRSTB nAddress
Strobe
PE
SLCT
This signal is active low. It is used to denote address read or
write operation.
Paper End
Printer Selected
Status
I
I
Same as SPP mode.
Same as SPP mode.
nERR
Error
I
Same as SPP mode.
Note 1: SPP and EPP can use 1 common register.
Note 2: nWrite is the only EPP output that can be over-ridden by SPP control port during an EPP cycle.
For correct EPP read cycles, PCD is required to be a low.
EXTENDED CAPABILITIES PARALLEL PORT
ECP provides a number of advantages, some of which are listed below. The individual features are
explained in greater detail in the remainder of this section.
High performance half-duplex forward and reverse channel Interlocked handshake, for fast reliable
transfer Optional single byte RLE compression for improved throughput (64:1) Channel addressing for
low-cost peripherals Maintains link and data layer separation Permits the use of active output drivers
permits the use of adaptive signal timing Peer-to-peer capability.
Vocabulary
The following terms are used in this document:
assert: When a signal asserts it transitions to a "true" state, when a signal deasserts it transitions to a
"false" state.
forward: Host to Peripheral communication.
reverse: Peripheral to Host communication
Pword: A port word; equal in size to the width of the LPC interface. For this implementation, PWord is
always 8 bits.
1:
0:
A high level.
A low level.
