READ A TRACK
DATA BUS
PHASE
Command
R/W D7
D6
MFM
0
D5 D4 D3
D2
0
D1
1
D0
0
REMARKS
Command Codes
W
W
W
0
0
0
0
0
0
0
0
HDS DS1 DS0
──────── C ────────
Sector ID information prior to Command
execution.
W
W
W
W
W
W
──────── H ────────
──────── R ────────
──────── N ────────
─────── EOT ───────
─────── GPL ───────
─────── DTL ───────
Execution
Result
Data transfer between the FDD and
system. FDC reads all of cylinders’
contents from index hole to EOT.
R
─────── ST0 ───────
Status information after Command
execution.
R
R
R
─────── ST1 ───────
─────── ST2 ───────
──────── C ────────
Sector ID information after Command
execution.
R
R
R
──────── H ────────
──────── R ────────
──────── N ────────
VERIFY
DATA BUS
D5 D4 D3
PHASE
R/W D7
D6
D2
D1
D0
REMARKS
Command
W
W
W
MT MFM SK
EC
1
0
0
0
1
1
0
Command Codes
0
0
HDS DS1 DS0
──────── C ────────
Sector ID information prior to
Command execution.
W
W
W
W
W
W
──────── H ────────
──────── R ────────
──────── N ────────
─────── EOT ───────
─────── GPL ───────
────── DTL/SC ──────
Execution
Result
No data transfer takes place.
R
─────── ST0 ───────
Status information after Command
execution.
R
R
R
─────── ST1 ───────
─────── ST2 ───────
──────── C ────────
Sector ID information after Command
execution.
R
R
R
──────── H ────────
──────── R ────────
──────── N ────────
