PA MODULE FOR CDMA / PCS (1850–1910 MHZ)
DATA SHEET • CX77107
Table 7. Practices to Avoid Induced Damage –GaAs IC Products
Wrist Straps
Personnel Grounding
Facility
Conductive Smocks, Gloves and Finger Cots
Antistatic ID Badges
Relative Humidity Control and Air Ionizers
Dissipative Floors (less than 109 Ω to GND)
Dissipative Table Tops
Protective Test Equipment (Properly Grounded)
Protective Workstation Grounded Tip Soldering Irons
Conductive Solder Suckers
Static Sensors
Bags and Pouches (Faraday Shield)
Protective Packaging
and Transportation
Protective Tote Boxes (Conductive Static Shielding)
Protective TraysGrounded Carts
Protective Work Order Holders
Figure 16. ESD Sensitivity Areas (Top View)
