ST7735
10.1.11 SLPOUT (11h): Sleep Out
11H
SLPOUT (Sleep Out)
Inst / Para
SLPOUT
D/CX
0
WRX
RDX
1
D17-8 D7
D6
0
D5
0
D4
1
D3
0
D2
0
D1
0
D0
1
HEX
(11h)
-
↑
-
0
Parameter
No Parameter
-This command turns off sleep mode.
Description
-In this mode the DC/DC converter is enabled, Internal display oscillator is started, and panel scanning is started.
-This command has no effect when module is already in sleep out mode. Sleep Out Mode can only be exit by the Sleep In
Command (10h).
-When IC is in Sleep In mode, it is necessary to wait 120msec before sending next command because of the stabilization
timing for the supply voltages and clock circuits.
Restriction
-When IC is in Sleep Out or Display On mode, it is necessary to wait 120msec before sending next command due to the
download of default value of registers and the execution of self-diagnostic function.
Status
Default Value
Sleep in mode
Sleep in mode
Sleep in mode
Power On Sequence
S/W Reset
Default
H/W Reset
Legend
SLPOUT
Command
Display whole blank
screen for 2 firames
(Automatic No effect
to DISP ON/OFF
Commands)
Parameter
Display
Start
Internal
Oscillator
Flow Chart
Start up
DC:DC
Display Memory
contents In
Converter
accordance with
the current
command table
settings
Action
Mode
Charge
Offset
voltage for
LCD
Sleep Out mode
Panel
Sequential
transter
V1.7
91
2009-12-04
