ST7735
10.1.10 SLPIN (10h): Sleep In
10H
SLPIN (Sleep In)
Inst / Para
SLPIN
D/CX
0
WRX
RDX
1
D17-8 D7
D6
0
D5
0
D4
1
D3
0
D2
0
D1
0
D0
0
HEX
(10h)
-
↑
-
0
Parameter
No Parameter
-This command causes the LCD module to enter the minimum power consumption mode.
Description
-In this mode the DC/DC converter is stopped, Internal display oscillator is stopped, and panel scanning is stopped.
-This command has no effect when module is already in Sleep In mode. Sleep In Mode can only be exit by the Sleep Out
Command (11h).
Restriction
-When IC is in Sleep Out or Display On mode, it is necessary to wait 120msec before sending next command because of
the stabilization timing for the supply voltages and clock circuits.
Status
Default Value
Sleep in mode
Sleep in mode
Sleep in mode
Power On Sequence
S/W Reset
Default
H/W Reset
Legend
Stop
DC-DC
Converte
r
SLPIN
Command
Parameter
Display
Display whole blank
screen (Automatic
No effect to DISP
ON/OFF
Stop
Internal
Oscillator
Commands)
Flow Chart
Drain
Charge
From LCD
Panel
Sleep In Mode
Action
Mode
Sequential
transter
V1.7
90
2009-12-04
SITRONIX [ SITRONIX TECHNOLOGY CO., LTD. ]
