ST7735
10.2.4 INVCTR (B4h): Display Inversion Control
B4H
Inst / Para
INVCTR
INVCTR (Display Inversion Control)
D/CX
WRX
RDX
D17-8 D7
D6
0
D5
1
D4
1
D3
0
D2
1
D1
0
D0
0
HEX
0
1
↑
↑
1
1
-
-
1
0
(B4h)
Parameter
0
0
0
0
NLA
NLB
NLC
-Display Inversion mode control
-NLA: Inversion setting in full colors normal mode (Normal mode on)
NLA
0
Inversion setting in full Colors normal mode
Line Inversion
1
Frame Inversion
-NLB: Inversion setting in Idle mode (Idle mode on)
Description
NLB
0
Inversion setting in Idle mode
Line Inversion
1
Frame Inversion
-NLC: Inversion setting in full colors partial mode (Partial mode on / Idle mode off)
NLC
Inversion setting in full Colors partial mode
Line Inversion
0
1
Frame Inversion
Status
Default Value
NLA
1d
NLB
1d
NLC
1d
B4h
Power On Sequence
S/W Reset
03h
03h
03h
Default
1d
1d
1d
H/W Reset
1d
1d
1d
Flow Chart
V1.7
125
2009-12-04
