ST7669V
9.1.67 OTPSEL: SEL OTP(E4H)
Command
A0
0
/RD /WR
D7
D6
D5
1
D4
0
D3
0
D2
1
D1
0
D0
0
Hex
(E4h)
-
1
1
0
0
1
1
OTPSEL
1
MS1 MS0
0
1
1
0
0
0
Parameter
NOTE: “-“ Don’t care
Description
This command defines OTP selection for EEPROM control. Please see the table as below:
MS1 MS0
Mode
Disable
OTPC
OTPB
0
0
1
0
1
1
Restriction
Register
Status
Availability
Availability
Normal Mode On, Idle Mode Off, Sleep Out
Normal Mode On, Idle Mode On, Sleep Out
Partial Mode On, Idle Mode Off, Sleep Out
Partial Mode On, Idle Mode On, Sleep Out
Sleep In
Yes
Yes
Yes
Yes
Yes
Default
Status
Default Value (MS[1:0])
Power On Sequence
00
00
00
S/W Reset
H/W Reset
Ver 1.3
164/208
6/4/2008
