ST7669V
9.1.47 IdleImageSaving: Idle Image Saving Mode(BCH)
Command
RMWOUT
Parameter
A0
0
/RD /WR
D7
1
D6
0
D5
1
D4
1
D3
D2
D1
0
D0
0
Hex
(BCh)
1
1
0
0
1
1
-
1
0
0
0
0
IdleIm Sunit
0
0
Description
IdleIm: Idle Image (White/Black Image) Saving Mode Setting.
Sunit: Display compensation step unit setting.
Function
0
1
IdleIm
Sunit
White/Black Saving setting
Display compensation unit
n-line normal
Mode1
n-line off
Mode2
Restriction
Register
Status
Availability
Availability
Normal Mode On, Idle Mode Off, Sleep Out
Normal Mode On, Idle Mode On, Sleep Out
Partial Mode On, Idle Mode Off, Sleep Out
Partial Mode On, Idle Mode On, Sleep Out
Sleep In
Yes
Yes
Yes
Yes
Yes
Default
Status
Default Value
0CH
Power On Sequence
S/W Reset
0CH
H/W Reset
0CH
Ver 1.3
142/208
6/4/2008
