EFR32MG13 Mighty Gecko Multi-Protocol Wireless SoC Family Data Sheet
Pin Definitions
GPIO Name
Pin Alternate Functionality / Description
Timers Communication Radio
Analog
Other
US0_TX #28
US0_RX #27
US0_CLK #26
US0_CS #25
US0_CTS #24
US0_RTS #23
US1_TX #28
US1_RX #27
US1_CLK #26
US1_CS #25
US1_CTS #24
US1_RTS #23
US2_TX #17
US2_RX #16
US2_CLK #15
US2_CS #14
US2_CTS #13
US2_RTS #12
LEU0_TX #28
LEU0_RX #27
I2C0_SDA #28
I2C0_SCL #27
TIM0_CC0 #28
TIM0_CC1 #27
TIM0_CC2 #26
TIM0_CDTI0 #25
TIM0_CDTI1 #24
TIM0_CDTI2 #23
TIM1_CC0 #28
FRC_DCLK #28
FRC_DOUT #27
PRS_CH0 #4
PRS_CH1 #3
PRS_CH2 #2
PRS_CH3 #1
ACMP0_O #28
ACMP1_O #28
FRC_DFRAME #26
MODEM_DCLK #28
MODEM_DIN #27
MODEM_DOUT #26
MODEM_ANT0 #25
MODEM_ANT1 #24
BUSBY
BUSAX
PF4
TIM1_CC1 #27
TIM1_CC2 #26
TIM1_CC3 #25
LETIM0_OUT0 #28
LETIM0_OUT1 #27
PCNT0_S0IN #28
PCNT0_S1IN #27
