EFR32MG13 Mighty Gecko Multi-Protocol Wireless SoC Family Data Sheet
Pin Definitions
GPIO Name
Pin Alternate Functionality / Description
Analog
Timers
Communication
Radio
Other
TIM0_CC0 #11
TIM0_CC1 #10
TIM0_CC2 #9
US0_TX #11
US0_RX #10
US0_CLK #9
US0_CS #8
TIM0_CDTI0 #8
TIM0_CDTI1 #7
TIM0_CDTI2 #6
TIM1_CC0 #11
CMU_CLK0 #2
CMU_CLKI0 #2
PRS_CH0 #8
US0_CTS #7
US0_RTS #6
US1_TX #11
US1_RX #10
US1_CLK #9
US1_CS #8
FRC_DCLK #11
FRC_DOUT #10
TIM1_CC1 #10
TIM1_CC2 #9
FRC_DFRAME #9
MODEM_DCLK #11
MODEM_DIN #10
MODEM_DOUT #9
MODEM_ANT0 #8
MODEM_ANT1 #7
PRS_CH9 #11
PRS_CH10 #0
PRS_CH11 #5
ACMP0_O #11
ACMP1_O #11
ETM_TCLK #3
BUSBY
BUSAX
TIM1_CC3 #8
PC6
WTIM0_CC0 #26
WTIM0_CC1 #24
WTIM0_CC2 #22
WTIM0_CDTI0 #18
WTIM0_CDTI1 #16
WTIM0_CDTI2 #14
LETIM0_OUT0 #11
LETIM0_OUT1 #10
PCNT0_S0IN #11
PCNT0_S1IN #10
US1_CTS #7
US1_RTS #6
LEU0_TX #11
LEU0_RX #10
I2C0_SDA #11
I2C0_SCL #10
