EFR32MG13 Mighty Gecko Multi-Protocol Wireless SoC Family Data Sheet
Pin Definitions
GPIO Name
Pin Alternate Functionality / Description
Analog
Timers
Communication
Radio
Other
TIM0_CC0 #10
TIM0_CC1 #9
TIM0_CC2 #8
US0_TX #10
US0_RX #9
TIM0_CDTI0 #7
TIM0_CDTI1 #6
TIM0_CDTI2 #5
TIM1_CC0 #10
TIM1_CC1 #9
US0_CLK #8
US0_CS #7
US0_CTS #6
US0_RTS #5
US1_TX #10
US1_RX #9
FRC_DCLK #10
FRC_DOUT #9
CMU_CLK0 #1
PRS_CH6 #10
PRS_CH7 #9
PRS_CH8 #8
PRS_CH9 #7
ACMP0_O #10
ACMP1_O #10
TIM1_CC2 #8
FRC_DFRAME #8
MODEM_DCLK #10
MODEM_DIN #9
MODEM_DOUT #8
MODEM_ANT0 #7
MODEM_ANT1 #6
BUSCY
BUSDX
TIM1_CC3 #7
PB15
WTIM0_CC0 #19
WTIM0_CC1 #17
WTIM0_CC2 #15
WTIM0_CDTI0 #11
WTIM0_CDTI1 #9
WTIM0_CDTI2 #7
LETIM0_OUT0 #10
LETIM0_OUT1 #9
PCNT0_S0IN #10
PCNT0_S1IN #9
US1_CLK #8
US1_CS #7
LFXTAL_P
US1_CTS #6
US1_RTS #5
LEU0_TX #10
LEU0_RX #9
I2C0_SDA #10
I2C0_SCL #9
