EFM32G Data Sheet
Revision History
13.2 Revision 2.00
May 10th, 2017
Consolidated all EFM32G data sheets:
• EFM32G200
• EFM32G210
• EFM32G222
• EFM32G230
• EFM32G232
• EFM32G280
• EFM32G290
• EFM32G840
• EFM32G842
• EFM32G880
• EFM32G890
New formatting throughout.
Added 1. Feature List.
Updated ordering codes in 2. Ordering Information for Revision E and tape and reel.
Added Figure 2.1 Ordering Code Decoder on page 5.
Separated Memory Map figure into Figure 3.2 System Address Space with Core and Code Space Listing on page 27 and Figure
3.3 System Address Space with Peripheral Listing on page 28 for readability.
Removed footnote for storage temperature range in 4.2 Absolute Maximum Ratings.
In 4.6 Power Management:
• Updated EM0 condition for VBODextthr- specification.
• Added VBODextthr- in EM1 and EM2 specifications.
• Updated EM0 condition for VBODextthr+ specification.
Updated Flash page erase time and device erase time in 4.7 Flash and added footnotes.
Updated figures in 4.9.3 LFRCO.
Updated figures and HFRCO current consumption typical values in 4.9.4 HFRCO.
In 4.10 Analog Digital Converter (ADC):
• Updated test conditions, updated specifications, and added footnote for average active current.
• Added input bias current.
• Added input offset current.
• Updated ADC clock frequency.
• Updated SNR, SINAD and SFDR.
• Updated offset voltage.
• Updated missing codes.
• Added gain error drift and offset error drift.
• Added VREF output voltage, VREF voltage drift, VREF temperature drift, VREF current consumption, and ADC and DAC VREF
matching.
In 4.11 Digital Analog Converter (DAC):
• Updated IDAC parameter, test conditions, and footnote.
• Added DAC load current specification to 4.11 Digital Analog Converter (DAC).
• Added VREF output voltage, VREF voltage drift, VREF temperature drift, VREF current consumption, and ADC and DAC VREF
matching.
Updated ACMP active current (BIASPROG=0b1111, FULLBIAS=1 and HALFBIAS=0 in ACMPn_CTRL register) typical value in
4.12 Analog Comparator (ACMP).
Updated VCMP hysteresis typical value in 4.13 Voltage Comparator (VCMP).
silabs.com | Building a more connected world.
Rev. 2.10 | 196
