EFM32G Data Sheet
Pin Definitions
5.9 EFM32G880 (LQFP100)
5.9.1 Pinout
The EFM32G880 pinout is shown in the following figure and table. Alternate locations are denoted by "#" followed by the location num-
ber (Multiple locations on the same pin are split with "/"). Alternate locations can be configured in the LOCATION bitfield in the
*_ROUTE register in the module in question.
Figure 5.9. EFM32G880 Pinout (top view, not to scale)
Table 5.25. Device Pinout
LQFP100 Pin#
Pin Alternate Functionality / Description
and Name
Pin # Pin Name
Analog
EBI
Timers
Communication
Other
LCD_SEG
13
1
2
3
PA0
PA1
PA2
EBI_AD09 #0
TIM0_CC0 #0/1
I2C0_SDA #0
LCD_SEG
14
EBI_AD10 #0
EBI_AD11 #0
TIM0_CC1 #0/1
TIM0_CC2 #0/1
I2C0_SCL #0
CMU_CLK1 #0
CMU_CLK0 #0
LCD_SEG
15
