EFM32G Data Sheet
Pin Definitions
BGA112 Pin# and
Name
Pin Alternate Functionality / Description
Pin # Pin Name
Analog
EBI
Timers
Communication
Other
A6
A7
A8
A9
PF7
PF5
PF4
PE4
TIM0_CC1 #2
TIM0_CDTI2 #2
TIM0_CDTI1 #2
U0_RX #0
EBI_REn #0
EBI_WEn #0
US0_CS #1
U0_TX #3
TIM0_CDTI1 #1/3
TIM1_CC1 #0
PCNT0_S1IN #0
ACMP1_C
H6
A10
A11
PC14
PC15
ACMP1_C
H7
TIM0_CDTI2 #1/3
TIM1_CC2 #0
U0_RX #3
DBG_SWO #1
B1
B2
B3
B4
B5
B6
B7
B8
B9
PA15
PE13
PE11
PE8
EBI_AD08 #0
EBI_AD05 #0
EBI_AD03 #0
EBI_AD00 #0
EBI_CS2 #0
US0_CS #0
US0_RX #0
ACMP0_O #0
BOOT_RX
TIM1_CC1 #1
PCNT2_S0IN #1
PD11
PF8
TIM0_CC2 #2
TIM0_CC0 #2
TIM0_CDTI0 #2
PF6
U0_TX #0
PF3
EBI_ALE #0
PE5
US0_CLK #1
ACMP1_C
H4
B10
B11
PC12
PC13
CMU_CLK0 #1
TIM0_CDTI0 #1/3
TIM1_CC0 #0
PCNT0_S0IN #0
ACMP1_C
H5
C1
C2
C3
C4
C5
C6
C7
PA1
PA0
EBI_AD10 #0
EBI_AD09 #0
EBI_AD02 #0
TIM0_CC1 #0/1
TIM0_CC0 #0/1
TIM1_CC0 #1
I2C0_SCL #0
I2C0_SDA #0
US0_TX #0
CMU_CLK1 #0
BOOT_TX
PE10
PD13
PD12
PF9
EBI_CS3 #0
VSS
Ground.
ACMP1_O #0
DBG_SWO #0
C8
C9
PF2
PE6
EBI_ARDY #0
US0_RX #1
US0_RX #2
ACMP1_C
H2
C10
PC10
TIM2_CC2 #2
ACMP1_C
H3
C11
PC11
US0_TX #2
U0_TX #2
D1
D2
PA3
PA2
EBI_AD12 #0
EBI_AD11 #0
TIM0_CDTI0 #0
TIM0_CC2 #0/1
CMU_CLK0 #0
Rev. 2.10 | 115
