EFM32G Data Sheet
Pin Definitions
5.6 EFM32G290 (BGA112)
5.6.1 Pinout
The EFM32G290 pinout is shown in the following figure and table. Alternate locations are denoted by "#" followed by the location num-
ber (Multiple locations on the same pin are split with "/"). Alternate locations can be configured in the LOCATION bitfield in the
*_ROUTE register in the module in question.
Figure 5.6. EFM32G280 Pinout (top view, not to scale)
Table 5.16. Device Pinout
BGA112 Pin# and
Pin Alternate Functionality / Description
Name
Pin # Pin Name
Analog
EBI
Timers
Communication
LEU0_RX #2
LEU0_TX #2
US0_CLK #0
Other
A1
A2
A3
A4
A5
PE15
PE14
PE12
PE9
EBI_AD07 #0
EBI_AD06 #0
EBI_AD04 #0
EBI_AD01 #0
EBI_CS1 #0
TIM1_CC2 #1
PCNT2_S1IN #1
PD10
