STK433-070-E
STK433-000/-200/STK403-100Sr PCB PARTS LIST
PCB Name: STK403-000Sr/100Sr/200Sr PCBA
Component
STK433-030/-040
STK433-230/-240
STK433-060/-070
STK433-260/-270
STK403-090 to130
Location No. (*3)
PARTS
RATING
-
Hybrid IC#1 Pin Position
R01
-
c
ERG1SJ101
100Ω, 1W
enable
enable
enable
enable
enable
enable
R02, R03 (R4)
RN16S102FK
RN16S563FK
RN16S182FK
RN14S4R7FK
ERX1SJ4R7
ERX2SJR22
100MV100HC
50MV2R2HC
DD104-63B471K50
DD104-63CJ030C50
10MV10HC
ECQ-V1H104JZ
DD104-63B***K50
RN16S302FK
-
1kΩ, 1/6W
56kΩ, 1/6W
1.8kΩ, 1/6W
4.7Ω, 1/4W
4.7Ω, 1W
0.22Ω, 2W
100μF, 100V
2.2μF, 50V
470pF, 50V
3pF, 50V
10μF, 10V
0.1μF, 50V
***pF, 50V
3kΩ, 1/6W
3μH
R05, R06, R08, R09 (R7, R10)
R11, R12 (R13)
R14, R15 (R16)
R17, R18 (R19)
R20, R21 (R22)
C01, C02, C03
C04, C05 (C06)
C07, C08 (C09)
C10, C11 (C12)
C13, C14 (C15)
C16, C17 (C18)
C19, C20 (C21)
R34, R35 (R36)
L01, L02 (L3)
short
enable
enable
enable (*1)
enable
enable (*2)
enable (*1)
enable
100pF
Short
enable
Stand-By Control Circuit
Tr1
2SC2274 (Reference)
GMB01 (Reference)
RN16S512FK
RN16S103FK
RN16S333FK
RN16S102FK
RN16S202FK
10MV33HC
-
VCE≥50V, IC≥10mA
Di
enable
D1
enable
R30
5.1kΩ, 1/6W
13kΩ, 1/6W
33kΩ, 1/6W
1kΩ, 1/6W
2kΩ, 1/6W
33μF, 10V
-
STK433-*00series
STK403-100series
enable
R31
R32
R33
C32
enable
enable
enable
J1, J2, J3, J4, J5, J6, J8, J9
enable
J7, JS2, JS3, JS4, JS5, JS7 JS8, JS9
-
-
-
JS6, JS10
JS1
-
-
enable
-
-
enable
(*1) Capacitor mark “A” side is “-” (negative).
(*2) STK433-200Sr (3ch) is 8pF use.
(*3) Location No.( ) parts is STK433-200Sr (3ch) only use.
No. A1488-5/11
