MultiMediaCardTM
Command Response Timing (Identification Mode)
There is just one Z bit period followed by P bits pushed up by the responding card. The following timing
diagram is relevalent for all host commands followed by a response, except CMD1,CMD2 and CMD3 :
Command Response Timing (Data Transfer Mode)
Card identification and card operation conditions timing
The card identification (CMD2) and card operation conditions (CMD1) timing are processed in the open-
drain mode. The card response to the host command starts after exactly NID clock cycles.
Identification Timing (Card Identification Mode)
Last Card Response - Next Host Command Timing
After receiving the last card response, the host can start the next command transmission after at least
NRC clock cycles. This timing is relevant for any host command.
Tming Response End to Next CMD Start (Data Transfer Mode)
Last Host Command - Next Host Command Timing
After the last command has been sent, the host can continue sending the next command after at least
NCC clock periods.
45
