OneNAND512Mb(KFG1216U2B-xIB6)
2.8 Registers
FLASH MEMORY
Section 2.8 of this specification provides information about the OneNAND512Mb registers.
2.8.1 Register Address Map
This map describes the register addresses, register name, register description, and host accessibility.
Address
(word order)
Address
(byte order)
Host
Access
Name
Description
Manufacturer identification
F000h
F001h
F002h
F003h
F004h
1E000h
1E002h
1E004h
1E006h
1E008h
Manufacturer ID
Device ID
R
R
R
R
R
Device identification
N/A
Version ID
Data Buffer size
Boot Buffer size
Data buffer size
Boot buffer size
Amount of
buffers
F005h
1E00Ah
R
Amount of data/boot buffers
F006h
F007h~F0FFh
F100h
1E00Ch
1E00Eh~1E1FEh
1E200h
Technology
Reserved
R
-
Info about technology
Reserved for user
Start address 1
Start address 2
Start address 3
R/W
-
NAND Flash Block Address
N/A
F101h
1E202h
F102h
1E204h
R/W
Destination Block address for Copy back program
Destination Page & Sector address for Copy
back program
F103h
1E206h
Start address 4
R/W
F104h
F105h
1E208h
1E20Ah
Start address 5
Start address 6
Start address 7
Start address 8
Reserved
-
N/A
-
N/A
F106h
1E20Ch
-
R/W
-
N/A
F107h
1E20Eh
NAND Flash Page & Sector address
Reserved for user
F108h~F1FFh
1E210h~1E3FEh
Buffer Number for the page data transfer to/from the
memory and the start Buffer Address
The meaning is with which buffer to start and how many
buffers to use for the data transfer
F200h
1E400h
Start Buffer
R/W
F201h~F207h
F208h~F21Fh
F220h
1E402h~1E40Eh
1E410h~1E43Eh
1E440h
Reserved
Reserved
Command
-
-
Reserved for user
Reserved for vendor specific purposes
Host control and memory operation commands
R/W
System
Configuration 1
F221h
F222h
1E442h
1E444h
R, R/W memory and Host Interface Configuration
System
Configuration 2
-
N/A
F223h~F22Fh
F230h~F23Fh
F240h
1E446h~1E45Eh
1E460h~1E47Eh
1E480h
Reserved
Reserved
-
Reserved for user
-
R
Reserved for vendor specific purposes
Controller Status and result of memory operation
Memory Command Completion Interrupt Status
Reserved for user
Controller Status
Interrupt
F241h
1E482h
R/W
-
F242h~F24Bh
1E484h~1E496h
Reserved
Start
Block Address
F24Ch
1E498h
R/W
Start memory block address in Write Protection mode
30
