OneNAND512Mb(KFG1216U2B-xIB6)
FLASH MEMORY
Equivalent to 1word of NAND Flash
Word
Address Address
Byte
Buf.
F
E
D
C
B
A
9
8
7
6
5
4
3
2
1
0
DataS 1_3 8048h
8049h
10090h
10092h
10094h
10096h
10098h
1009Ah
1009Ch
1009Eh
BI
Managed by Internal ECC logic
804Ah
Reserved for the future use
Managed by Internal ECC logic
804Bh
Reserved for the current and future use
804Ch
ECC Code for Main area data (2nd)
ECC Code for Spare area data (1st)
Reserved for the future use
ECC Code for Main area data (1st)
ECC Code for Main area data (3rd)
ECC Code for Spare area data (2nd)
804Dh
804Eh
804Fh
Free Usage
NOTE:
- BI: Bad block Information
>Host can use complete spare area except BI and ECC code area. For example,
Host can write data to Spare area buffer except for the area controlled by ECC logic at program operation.
>In case of ’with ECC’ mode, OneNAND automatically generates ECC code for both main and spare data of memory during program operation,
but does not update ECC code to spare bufferRAM during load operation.
>When loading/programming spare area, spare area BufferRAM address(BSA) and BufferRAM sector count(BSC) is chosen via Start buffer register
as it is.
29
