Datasheet
RGSX5TS65E
lElectrical Characteristic Curves
Fig.13 Typical Switching Energy Losses
Fig.14 Typical Switching Energy Losses
vs. Gate Resistance
vs. Collector Current
100
100
10
1
Eon
Eon
10
Eoff
Eoff
1
VCC = 400V, VGE = 15V,
IC = 75A, Tj = 175ºC
Inductive load
VCC = 400V, VGE = 15V,
RG = 10Ω, Tj = 175ºC
Inductive load
0.1
0.1
0
25 50 75 100 125 150
Collector Current : IC [A]
0
10
20
30
40
50
Gate Resistance : RG [Ω]
Fig.15 Typical Capacitance vs. Collector
Emitter to Voltage
Fig.16 Typical Gate Charge
15
10000
VCC = 300V
VCC = 200V
Cies
1000
100
10
10
5
Coes
VCC = 400V
Cres
f = 1MHz
VGE = 0V
Tj = 25ºC
IC = 75A
Tj = 25ºC
1
0
0.01
0.1
1
10
100
0
15 30 45 60 75 90
Gate Charge : QG [nQ]
Collector To Emitter Voltage : VCE [V]
www.rohm.com
© 2021 ROHM Co., Ltd. All rights reserved.
2021.01 - Rev.A
8/11
