● Thermal loss
The thermal design should set operation for the following conditions.
(Since the temperature shown below is the guaranteed temperature, be sure to take a margin into account.)
1. The ambient temperature Ta must be 105℃ or less.
2. The IC’s loss must be within the allowable dissipation Pd.
The thermal abatement characteristics are as follows.
(PCB: 70 mm × 70mm × 1.6 mm, mounted on glass epoxy single – layer substrate)
1000
900
800
700
600
500
400
300
200
100
0
0
25
50
75
100
125
150
Ta[℃]
Figure 18. SOP8 Thermal Abatement Characteristics
