BD9109FVM-LB
Absolute Maximum Ratings(Ta=25°C)
Parameter
Symbol
Rating
Unit
VCC Voltage
VCC
PVCC
EN
-0.3 to +7 (Note 1)
-0.3 to +7 (Note 1)
-0.3 to +7
V
V
PVCC Voltage
EN Voltage
V
SW, ITH Voltage
SW,ITH
Pd1
-0.3 to +7
V
Power Dissipation 1
Power Dissipation 2
Operating Temperature Range
Storage Temperature Range
387.5 (Note 2)
587.4 (Note 3)
-25 to +85
-55 to +150
+150
mW
mW
°C
°C
°C
Pd2
Topr
Tstg
EN Voltage
Tjmax
(Note 1) Pd should not be exceeded.
(Note 2) Derating in done 3.1mW/℃ for temperatures above Ta=25℃
(Note 3) Derating in done 4.7mW/℃ for temperatures above Ta=25℃,Mounted on 70mm×70mm×1.6mm Glass Epoxy PCB.
Caution: Operating the IC over the absolute maximum ratings may damage the IC. The damage can either be a short circuit between pins or an open circuit
between pins and the internal circuitry. Therefore, it is important to consider circuit protection measures, such as adding a fuse, in case the IC is operated over
the absolute maximum ratings.
Recommended Operating Conditions(Ta=25°C)
Parameter
Symbol
Min
Typ
Max
Unit
VCC (Note 4)
PVCC (Note 4)
EN
5.0
5.0
-
V
V
V
A
VCC voltage
PVCC voltage
EN voltage
4.5
4.5
0
5.5
5.5
VCC
0.8
Isw (Note 4)
-
SW average output current
-
(Note 4) Pd should not be exceeded.
Electrical Characteristics(Unless otherwise specified Ta=25°C VCC=PVCC=5V EN=VCC)
Parameter
Standby current
Symbol
Min
Typ
Max
Unit
Conditions
ISTB
ICC
-
-
0
250
GND
VCC
1
10
400
0.8
-
μA
μA
V
EN=GND
Bias current
EN Low voltage
VENL
VENH
IEN
-
Standby mode
Active mode
VEN=5V
EN High voltage
2.0
-
V
EN input current
10
μA
MHz
Ω
Oscillation frequency
Pch FET ON resistance (Note 5)
Nch FET ON resistance (Note 5)
Output voltage
FOSC
RONP
RONN
VOUT
ITHSI
0.8
-
1
1.2
0.60
0.50
3.366
-
0.35
0.25
3.300
20
PVCC=5V
PVCC=5V
-
Ω
3.234
10
10
3.6
3.65
0.5
1
V
ITH SInk current
μA
μA
V
VOUT =H
VOUT =L
ITH Source Current
UVLO threshold voltage
UVLO hysteresis voltage
Soft start time
ITHSO
VUVLO1
VUVLO2
TSS
20
-
3.8
3.9
1
4.0
4.2
2
VCC=H→L
VCC=L→H
V
ms
ms
Timer latch time
TLATCH
2
3
SCP/TSD operated
Output Short circuit
Threshold Voltage
VSCP
-
2
2.7
V
VOUT =H→L
(Note 5) Outgoing inspection is not done on all products
