RT8841
Table 4. Output Voltage Program (K8_M2)
Pin Name
Nominal Output Voltage DACOUT
VID5
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
VID4
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
VID3
0
0
0
0
0
0
1
1
1
1
1
1
1
1
0
0
0
0
0
0
0
0
1
1
1
1
1
1
1
1
VID2
0
0
1
1
1
1
0
0
0
0
1
1
1
1
0
0
0
0
1
1
1
1
0
0
0
0
1
1
1
1
VID1
1
1
0
0
1
1
0
0
1
1
0
0
1
1
0
0
1
1
0
0
1
1
0
0
1
1
0
0
1
1
VID0
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0.7375
0.7250
0.7125
0.7000
0.6875
0.6750
0.6625
0.6500
0.6375
0.6250
0.6125
0.6000
0.5875
0.5750
0.5625
0.5500
0.5375
0.5250
0.5125
0.5000
0.4875
0.4750
0.4625
0.4500
0.4375
0.4250
0.4125
0.4000
0.3875
0.3750
Note: (1) 0 : Connected to GND
(2) 1 : Open
(3) The voltage above are load independent for desktop and server platforms. For mobile platforms the voltage above
correspond to zero load current.
