Proposed
RFFC5071/5072
Absolute Maximum Ratings
Caution! ESD sensitive device.
Parameter
Rating
Unit
Exceeding any one or a combination of the Absolute Maximum Rating conditions may
cause permanent damage to the device. Extended application of Absolute Maximum
Rating conditions to the device may reduce device reliability. Specified typical perfor-
mance or functional operation of the device under Absolute Maximum Rating condi-
tions is not implied.
Supply Voltage (VDD
)
-0.5 to +3.6
V
Input Voltage (VIN) any pin
-0.3 to VDD+0.3
V
RF/IF mixer input power
+15
dBm
°C
RoHS status based on EUDirective2002/95/EC (at time of this document revision).
Operating Temperature Range
Storage Temperature Range
-40 to +85
-40 to +150
The information in this publication is believed to be accurate and reliable. However, no
responsibility is assumed by RF Micro Devices, Inc. ("RFMD") for its use, nor for any
infringement of patents, or other rights of third parties, resulting from its use. No
license is granted by implication or otherwise under any patent or patent rights of
RFMD. RFMD reserves the right to change component circuitry, recommended appli-
cation circuitry and specifications at any time without prior notice.
°C
Specification
Parameter
Unit
Condition
Min.
Typ.
Max.
ESD Requirementsl
Human Body Model
2000
1000
200
V
V
V
V
General
RF Pins
General
RF Pins
Machine Model
100
Operating Conditions
Supply voltage (VDD
)
2.7
-40
3.0
3.3
V
Temperature (TOP
)
+85
°C
Logic Inputs/Outputs (VDD=Supply to DIG_VDD pin)
Input low voltage
Input high voltage
-0.3
1.5
+0.5
VDD
V
V
Input low current
Input high current
-10
-10
+10
+10
A
A
Input=0V
Input=VDD
Output low voltage
Output high voltage
0
0.8*VDD
10
0.2*VDD
VDD
V
V
Load resistance
kΩ
Load capacitance
Static
20
pF
Supply Current (IDD) with 1GHz LO
100
125
mA
mA
mA
A
Low current, MIX_IDD=1, one mixer enabled.
High linearity, MIX_IDD=6, one mixer enabled.
Reference oscillator and bandgap only.
ENBL=0 and REF_STBY=0
Standby
2
Power Down Current
300
Mixer 1/2 (Mixer output driving 4:1 balun)
Gain
-2
dB
dB
Not including balun losses
Low current setting
Noise Figure
10
13
dB
High linearity setting
Low current setting
IIP3
+10
+23
dBm
dBm
MHz
dB
High linearity setting
Input port frequency range
Mixer input return loss
30
30
6000
4500
10
100Ω differential
Output port frequency range
Reference Oscillator
MHz
External reference frequency
Reference divider ratio
10
1
104
7
MHz
External reference input level
500
800
1500
mVp-p
AC-coupled
