R8C/13 Group Hardware Manual
REVISION HISTORY
Rev.
Date
Description
Summary
Page
1.20 Jan.27.2006
139
140
141
142
146
Figure 15.2 Programmable I/O Ports (2); NOTES: 1 added
Figure 15.3 Programmable I/O Ports (3); NOTES: 1 added
Figure 15.4 Programmable I/O Ports (4); NOTES: 1 added
Figure 15.5 Programmable I/O Ports (5); NOTES: 3 added
Table 15.9 Port P10/KI0/AN8/CMP00 Setting;
Setting value: Output port, P1 deleted
147
Table 15.10 Port P11/KI1/AN9/CMP01 Setting;
Setting value: Output port, P1 deleted
Table 15.11 Port P12/KI2/AN10/CMP02 Setting;
Setting value: Output_p__o__r__t_,__P__1 deleted
149
Table 15.17 Port P30/CNTR0/CMP10 Setting;
P3 deleted
Table 15.18 Port P31/TZOUT/CMP11 Setting;
P3 deleted
_______
Table 15.19 Port P32/INT2/CNTR1/CMP12 Setting;
P3 deleted
_______
150
Table 15.20 Port P33/INT3/TCIN Setting; Bit: “PD3_1” → “PD3_3”
_______
Table 15.22 Port P45/INT0 Setting; Bit: “PD3_3” → “PD4_5”
Table 15.23 Port XIN/P46, XOUT/P47 Setting;
Setting value: External input to XIN pin, “H” output from XOUT pin;
CM1: “1” → “0”, CM0: “0” → “1”, Feedback resistance: “OFF” → “ON”
Table 16.2 Recommended Operating Conditions; NOTES: 1, 2, 3 revised
Table 16.3 A/D Conversion Characteristics;
152
153
“A/D operation clock frequency” → “A/D operating clock frequency” revised
NOTES: 1, 2, 3, 4 revised
154
155
Table 16.4 Flash Memory (Program ROM) Electrical Characteristics;
“Data retention duration” → “Data hold time” revised
“Topr” → “Ambient temperature” revised
NOTES: 1 to 7 added
Measuring condition of byte program time and block erase time deleted
Table 16.5 Flash Memory (Data flash Block A, Block B) Electrical characteristics
“Data retention duration” → “Data hold time” revised
“Topr” → “Ambient temperature” revised
NOTES: 1, 3 revised, NOTES: 9 added
Measuring condition of byte program time and block erase time deleted
Table 16.7 Reset Circuit Electrical Characteristics (When Using Hardware Reset 2)
NOTES: 3 (Vpor1) added
156
157
Table 16.9 High-speed On-Chip Oscillator Circuit Electrical Characteristics;
“High-speed on-chip oscillator temperature dependence”
→
“High-speed on-chip oscillator frequency temperature dependence” revised
Table 16.11 Electrical Characteristics (1) [VCC=5V];
“P10 to P17 Except XOUT” → “Except P10 to P17, XOUT” revised
Table 16.12 Electrical Characteristics (2) [VCC=5V];
NOTES: 1, 2 revised
158
Measuring condition: Stop mode “Topr=25 °C” added
Table 16.18 Electrical Characteristics (3) [VCC=3V]
“P10 to P17 Except XOUT” → “Except P10 to P17, XOUT” revised
Table 16.19 Electrical Characteristics (4) [VCC=3V];
NOTES: 1, 2 revised
161
162
Measuring condition: Stop mode “Topr=25 °C” added
C-5
