R8C/13 Group
16. Electrical Characteristics
Timing requirements [VCC=3V] (Unless otherwise noted: VCC = 3V, VSS = 0V at Topr = 25 °C)
Table 16.20 XIN input
Standard
Symbol
Unit
Parameter
Min.
100
40
Max.
tC(XIN)
tWH(XIN)
tWL(XIN)
ns
ns
ns
XIN input cycle time
XIN input HIGH pulse width
XIN input LOW pulse width
–
–
–
40
________
Table 16.21 CNTR0 input, CNTR1 input, INT2 input
Standard
Symbol
Unit
Parameter
Min.
300
120
120
Max.
tC(CNTR0)
tWH(CNTR0)
tWL(CNTR0)
ns
ns
ns
–
–
–
CNTR0 input cycle time
CNTR0 input HIGH pulse width
CNTR0 input LOW pulse width
________
Table 16.22 TCIN input, INT3 input
Standard
Symbol
Unit
Parameter
Min.
1200(1)
600(2)
600(2)
Max.
tC(TCIN)
tWH(TCIN)
tWL(TCIN)
ns
ns
ns
–
–
–
TCIN input cycle time
TCIN input HIGH pulse width
TCIN input LOW pulse width
NOTES:
1. When using the Timer C input capture mode, adjust the cycle time above ( 1/ Timer C count source
frequency x 3).
2. When using the Timer C input capture mode, adjust the pulse width above ( 1/ Timer C count source
frequency x 1.5).
Table 16.23 Serial Interface
Symbol
Unit
Standard
Parameter
Min.
Max.
–
–
–
160
–
–
–
tC(CK)
ns
ns
ns
ns
ns
ns
ns
300
150
150
–
0
55
90
CLKi input cycle time
tW(CKH)
tW(CKL)
td(C-Q)
th(C-Q)
tsu(D-C)
th(C-D)
CLKi input HIGH pulse width
CLKi input LOW pulse width
TxDi output delay time
TxDi hold time
RxDi input setup time
RxDi input hold time
________
Table 16.24 External interrupt INT0 input
Standard
Symbol
Unit
Parameter
Min.
380(1)
380(2)
Max.
–
–
________
tW(INH)
tW(INL)
ns
ns
INT0 input HIGH pulse width
________
INT0 input LOW pulse width
NOTES:
________
________
1. When selecting the digital filter by the INT0 input filter select bit, use the INT0 input HIGH pulse width
to the greater value,either ( 1/ digital filter clock frequency x 3) or the minimum value of standard.
________
________
2 . When selecting the digital filter by the INT0 input filter select bit, use the INT0 input LOW pusle width
to the greater value,either ( 1/ digital filter clock frequency x 3) or the minimum value of standard.
Rev.1.20 Jan 27, 2006 page 163 of 205
REJ09B0111-0120
