PS2801A-1,PS2801A-4
ELECTRICAL CHARACTERISTICS (TA = 25 °C)
Parameter
Symbol
VF
Conditions
MIN.
TYP.
1.2
MAX.
1.4
5
Unit
V
Diode
Forward Voltage
Reverse Current
Terminal Capacitance
IF = 5 mA
VR = 5 V
IR
µA
pF
nA
Ct
V = 0 V, f = 1.0 MHz
VCE = 70 V, IF = 0 mA
10
Collector to Emitter Dark
Current
Transistor
Coupled
ICEO
100
400
0.3
Current Transfer Ratio
(IC/IF)*1
CTR
IF = 5 mA, VCE = 5 V
IF = 10 mA, IC = 2 mA
50
%
V
Collector Saturation
Voltage
VCE(sat)
0.13
Isolation Resistance
Isolation Capacitance
Rise Time*2
RI-O
CI-O
tr
VI-O = 1.0 kVDC
1011
Ω
V = 0 V, f = 1.0 MHz
0.4
5
pF
µs
VCC = 5 V, IC = 2 mA, RL = 100 Ω
Fall Time*2
tf
7
*1 CTR rank
PS2801A-1
N : 50 to 400 (%)
P : 150 to 300 (%)
L : 100 to 300 (%)
PS2801A-4
N : 50 to 400 (%)
*2 Test circuit for switching time
Pulse Input
V
CC
PW = 100 µs
Duty Cycle = 1/10
I
F
V
OUT
50 Ω
RL = 100 Ω
5
Data Sheet PN10398EJ01V0DS
