PMC-Sierra, Inc.
PRELIMINARY
PM5381 S/UNI-2488
DATASHEET
PMC-2000489
ISSUE 1
SATURN USER NETWORK INTERFACE FOR 2488 MBIT/S
Register 0864H: T8TE APS1 Test Pattern
Register 086CH: T8TE APS2 Test Pattern
Register 0874H: T8TE APS3 Test Pattern
Register 087CH: T8TE APS4 Test Pattern
Bit
Type
Function
Default
Bit 15
Bit 14
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
Unused
Unused
Unused
Unused
Unused
Unused
TP[9]
X
X
X
X
X
X
1
0
1
0
1
0
1
0
1
0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Bit 8
TP[8]
Bit 7
TP[7]
Bit 6
TP[6]
Bit 5
TP[5]
Bit 4
TP[4]
Bit 3
TP[3]
Bit 2
TP[2]
Bit 1
TP[1]
Bit 0
TP[0]
TP[9:0]:
The Test Pattern registers (TP[9:0]) contains the test pattern that is used to insert into the
outgoing data stream for jitter test purpose. When the TPINS bit is set high, the test pattern
stored in TP[9:0] is used to replace all the overhead and payload bytes of the output data
stream.
Proprietary and Confidentail to PMC-Sierra Inc., and for its Customer’s Internal Use
418
