PMC-Sierra, Inc.
PRELIMINARY
PM5381 S/UNI-2488
DATASHEET
PMC-2000489
ISSUE 1
SATURN USER NETWORK INTERFACE FOR 2488 MBIT/S
Register 0840H: R8TD APS1 Control and Status
Register 0848H: R8TD APS2 Control and Status
Register 0850H: R8TD APS3 Control and Status
Register 0858H: R8TD APS4 Control and Status
Bit
Type
Function
Default
Bit 15
Bit 14
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
R/W
DLBEN
Unused
Unused
Unused
Unused
Unused
PININV
OFAAIS
FUOE
0
X
X
X
X
X
0
R/W
R/W
R/W
R/W
R/W
R/W
R
Bit 8
0
Bit 7
0
Bit 6
LCVE
0
Bit 5
OFAE
0
Bit 4
OCAE
OFAV
0
Bit 3
X
X
X
X
Bit 2
R
OCAV
Bit 1
W
FOFA
Bit 0
W
FOCA
FOCA:
The force out-of-character-alignment bit (FOCA) controls the operation of the character
alignment circuit on a serial link. A transition from logic zero to logic one in this bit forces the
receiver to the out-of-character-alignment state where it will search for the transport frame
alignment character (K28.5). This bit must be manually set to logic zero before it can be used
again.
FOFA:
The force out-of-frame-alignment bit (FOFA) controls the operation of the frame alignment
circuit. A transition from logic zero to logic one in this bit forces the receiver to the out-of-
frame-alignment state where it will search for the transport frame alignment character
(K28.5). This bit must be manually set to logic zero before it can be used again.
Proprietary and Confidentail to PMC-Sierra Inc., and for its Customer’s Internal Use
405
