PMC-Sierra, Inc.
PRELIMINARY
PM5381 S/UNI-2488
DATASHEET
PMC-2000489
ISSUE 1
SATURN USER NETWORK INTERFACE FOR 2488 MBIT/S
Register 0790H: SIRP Configuration Timeslot
Bit
Type
Function
Default
Bit 15
Bit 14
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
Unused
Unused
X
X
X
X
0
0
0
0
0
0
0
0
0
1
1
0
Unused
Unused
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
TSx_RDI[1]
TSx_RDI[0]
TSx_REI[3]
TSx_REI[2]
TSx_REI[1]
TSx_REI[0]
Tsx_FORCE_LCD
TSx_RDI20F
TSx_ERDI
Bit 8
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
TSx_RMODE[1]
TSx_RMODE[0]
TSx_PROV
Bit 1
Bit 0
TSx_PROV:
When TSx_PROV is logic 0, automatic remote alarm reporting is disabled for the APS In bus
into the THPP. When TSx_PROV is logic 1, automatic remote alarm reporting is enabled for
the APS In data stream to the THPP.
TSx_RMODE[1:0]:
The TSx_RMODE[1:0] bits identify the mode of reporting STS Path Remote Defect
Indications (RDI) as shown in Table 13.
