PMC-Sierra, Inc.
PRELIMINARY
PM5381 S/UNI-2488
DATASHEET
PMC-2000489
ISSUE 1
SATURN USER NETWORK INTERFACE FOR 2488 MBIT/S
Register 078AH: TXPHY Interrupt Enable
Bit
Type
Function
Default
Bit 15
Bit 14
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
Unused
Unused
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
Unused
Unused
Unused
Unused
Unused
Bit 8
Unused
Bit 7
Unused
Bit 6
Unused
Bit 5
Unused
Bit 4
Unused
Bit 3
Unused
Bit 2
R/W
R/W
R/W
TDTFERRE
TPARERRE
RUNTCELLE
Bit 1
Bit 0
RUNTCELLE
The RUNTCELLE bit is used to enable the detection of the runt cell condition (RUNTCELLI)
to assert a hardware interrupt on the INTB pin. When set to logic 0, the hardware interrupt is
masked. When set to logic 1, the hardware interrupt is enabled.
TPARERRE
The TPARERRE bit is used to enable the detection of a parity error (TPARERRI) to assert a
hardware interrupt on the INTB pin. When set to logic 0, the hardware interrupt is masked.
When set to logic 1, the hardware interrupt is enabled.
TDTFERRE
The TDTFERRE bit is used to enable the TDFTERRI interrupt status bit to assert a hardware
interrupt on the INTB pin. When set to logic 0, the hardware interrupt is masked. When set
to logic 1, the hardware interrupt is enabled.
Proprietary and Confidentail to PMC-Sierra Inc., and for its Customer’s Internal Use
375
