PMC-Sierra, Inc.
PRELIMINARY
PM5381 S/UNI-2488
DATASHEET
PMC-2000489
ISSUE 1
SATURN USER NETWORK INTERFACE FOR 2488 MBIT/S
Register 0785H: RXPHY Calendar Indirect Address Data
Bit
Type
Function
Default
Bit 15
Bit 14
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
R
BUSY
X
0
0
0
0
0
0
0
0
X
0
0
0
0
0
0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
CALENDAR_ADDR[6]
CALENDAR_ADDR[5]
CALENDAR_ADDR[4]
CALENDAR_ADDR[3]
CALENDAR_ADDR[2]
CALENDAR_ADDR[1]
CALENDAR_ADDR[0]
CONFIG_RWB
Bit 8
Bit 7
Bit 6
Unused
Bit 5
R/W
R/W
R/W
R/W
R/W
R/W
CALENDAR_DATA[5]
CALENDAR_DATA[4]
CALENDAR_DATA[3]
CALENDAR_DATA[2]
CALENDAR_DATA[1]
CALENDAR_DATA[0]
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
The RXPHY Calendar Indirect Address Data register is an indirect address and data register. The
register is used in POS mode of operation
CALENDAR_DATA[5:0]
The CALENDAR_DATA register is provided to program the PHY address number to be
serviced in the calendar sequence. The calendar consists of a maximum of 128 entries
where the CALENDAR_ADDR is used to access one of the 128 (or less) entries to either
write or read CALENDAR_DATA. CALENDAR_DATA is the PHY address to be serviced
during the sequence associated with CALENDAR_ADDR. The length of the calendar is set in
the RXPHY Calendar Length register. For the S/UNI-2488, this register should be set to all
zeros.
CALENDAR_ADDR[6:0]
The CALENDAR_ADDR register is an indirect address register that is used with
CALENDAR_DATA register. The two registers together allow indirect address reads and
writes using a small amount of external address space. The CALENDAR_ADDR is used with
CONFIG_RWB and BUSY to command reads and writes.
