PMC-Sierra, Inc.
PRELIMINARY
PM5381 S/UNI-2488
DATASHEET
PMC-2000489
ISSUE 1
SATURN USER NETWORK INTERFACE FOR 2488 MBIT/S
Register 0782H: RXPHY Interrupt Enable
Bit
Type
Function
Default
Bit 15
Unused
X
Bit 14
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
Bit 8
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
Unused
RUNTCELLE
X
X
X
X
X
X
X
X
X
X
X
X
X
X
0
R/W
RUNTCELLE
The RUNTCELLE bit is used to enable RUNTCELLI signal to assert a hardware interrupt on
the INTB pin. When set to logic 0, the hardware interrupt is masked. When set to logic 1,
the hardware interrupt is enabled.
Proprietary and Confidentail to PMC-Sierra Inc., and for its Customer’s Internal Use
365
