Indirect Register 08H: THPP Transmit F2 and Z3
Bit
Type
Function
Default
Bit 15
Bit 14
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
F2[7]
F2[6]
F2[5]
F2[4]
F2[3]
F2[2]
F2[1]
F2[0]
Z3[7]
Z3[6]
Z3[5]
Z3[4]
Z3[3]
Z3[2]
Z3[1]
Z3[0]
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
Bit 8
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Z3[7:0]:
The Z3[7:0] bits are inserted in the Z3 byte position when the SRCZ3 bit of the THPP Source
& Pointer Control Register is logic 0 and input TPOHEN is low during the path Z3 growth bit
positions in the path overhead input stream, TPOH.
This field is only valid for THPP STS-1/STM0 #1.
F2[7:0]:
The F2[7:0] bits are inserted in the F2 byte position when the SRCF2 bit of the THPP Source
& Pointer Control Register is logic 0 and input TPOHEN is low during the path User Channel
bit positions in the path overhead input stream, TPOH.
This field is only valid for THPP STS-1/STM0 #1.
