PMC-Sierra, Inc.
PRELIMINARY
PM5381 S/UNI-2488
DATASHEET
PMC-2000489
ISSUE 1
SATURN USER NETWORK INTERFACE FOR 2488 MBIT/S
Indirect Register 07H: THPP Transmit H4 Mask and G1
Bit
Type
Function
Default
Bit 15
Bit 14
Bit 13
Bit 12
Bit 11
Bit 10
Bit 9
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
H4[7]
H4[6]
H4[5]
H4[4]
H4[3]
H4[2]
H4[1]
H4[0]
G1[7]
G1[6]
G1[5]
G1[4]
G1[3]
G1[2]
G1[1]
G1[0]
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
Bit 8
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
G1[7:0]:
The G1[7:0] bits are inserted in the G1 byte position when the SRCREI and SRCRDI bits of
the Source and Pointer Control Register are high and TPOHEN is low during the path status
bit positions in the path overhead input stream, TPOH.
This field is only valid for THPP STS-1/STM0 #1.
H4[7:0]:
The H4[7:0] bits are inserted in the H1 byte position when the ENH4MASK bit of the Source
and Pointer Control Register is high and TPOHEN is low during the path multiframe bit
positions in the path overhead input stream, TPOH.
This field is only valid for THPP STS-1/STM0 #1.
Proprietary and Confidentail to PMC-Sierra Inc., and for its Customer’s Internal Use
240
