STANDARD PRODUCT
PM5365 TEMAP
DATASHEET
PMC-1991148
ISSUE 3
HIGH DENSITY VT/TU MAPPER
AND M13 MULTIPLEXER
3720H-
373FH
3740H-
375FH
3780H-
379FH
3780H-
3FFFH
INSBI Test Registers
SBI SIPO Test Registers
SBI PISO Test Registers
Reserved
Notes on Register Bits:
1)
Writing values into unused register bits has no effect. Reading back
unused bits can produce either a logic one or a logic zero; hence unused bits
should be masked off by software when read.
2)
Writeable register bits are not initialized upon reset unless otherwise
noted.
