Philips Semiconductors
Product specification
New In Car Entertainment car radio tuner IC with
Precision Adjacent Channel Suppression (NICE-PACS)
TEA6848H
12.2.3 WRITE MODE: DATA BYTE 1
Table 7 Format of data byte 1
BIT 7
BIT 6
BIT 5
BIT 4
BIT 3
BIT 2
BIT 1
PLL1
BIT 0
PLL7
PLL6
PLL5
PLL4
PLL3
PLL2
PLL0
Table 8 Description of data byte 1 bits
BIT
SYMBOL
DESCRIPTION
7 to 0
PLL[7:0]
Setting of programmable counter of synthesizer PLL. Lower byte of PLL divider
word.
12.2.4 WRITE MODE: DATA BYTE 2
Table 9 Format of data byte 2
BIT 7
BIT 6
BIT 5
BIT 4
BIT 3
BIT 2
BIT 1
BIT 0
MUTE
DAA6
DAA5
DAA4
DAA3
DAA2
DAA1
DAA0
Table 10 Description of data byte 2 bits
BIT
SYMBOL
DESCRIPTION
7
MUTE
FM audio mute. If MUTE = 0, then FM audio not muted. If MUTE = 1, then FM audio
muted; writing to programmable divider and antenna DAA enabled.
6 to 0
DAA[6:0]
Setting of antenna digital auto alignment.
12.2.5 WRITE MODE: DATA BYTE 3
Table 11 Format of data byte 3
BIT 7
BIT 6
BIT 5
BIT 4
BIT 3
BIT 2
BIT 1
BIT 0
IFMT
FREF2
FREF1
FREF0
IFPR
BND1
BND0
AMFM
Table 12 Description of data byte 3 bits
BIT
SYMBOL
DESCRIPTION
7
IFMT
IF measuring time. If IFMT = 0, then IF measuring time is 20 ms. If IFMT = 1, then
IF measuring time is 2 ms.
6 to 4
FREF[2:0] Reference frequency for synthesizer. These 3 bits determine the reference
frequency, see Table 13.
3
2 and 1
0
IFPR
BND[1:0]
AMFM
IF counter prescaler ratio. If IFPR = 0, then IF prescaler ratio is 40. If IFPR = 1, then
IF prescaler ratio is 10.
Band switch. These 2 bits select in FM mode band and local or distant, see Table 14; in
AM mode band and AM stereo, see Table 15.
AM or FM switch. If AMFM = 0, then FM mode. If AMFM = 1, then AM mode.
2004 Nov 12
33
