Philips Semiconductors
Product specification
Triple video output amplifier
TDA6107Q
CHARACTERISTICS
Operating range: Tj = −20 to +150 °C; VDD = 180 to 210 V. Test conditions: Tamb = 25 °C; VDD = 200 V;
Vo(c1) = Vo(c2) = Vo(c3) = 1⁄2VDD; CL = 10 pF (CL consists of parasitic and cathode capacitance); Rth(h-a) = 18 K/W
(measured in test circuit of Fig.8); unless otherwise specified.
SYMBOL
PARAMETER
CONDITIONS
MIN.
5.9
TYP.
6.9
MAX.
7.9
UNIT
mA
Iq
quiescent supply current
Vref(int)
internal reference voltage
(input stage)
−
2.5
−
V
Ri
input resistance
gain of amplifier
gain difference
−
3.6
51.0
0
−
kΩ
G
47.5
−2.5
116
55.0
+2.5
142
∆G
VO(c)
nominal output voltage at
pins 7, 8 and 9 (DC value)
Ii = 0 µA
Ii = 0 µA
129
V
V
∆VO(c)(offset)
differential nominal output
offset voltage between
pins 7 and 8, 8 and 9 and
9 and 7 (DC value)
−
0
5
∆Vo(c)(T)
output voltage temperature
drift at pins 7, 8 and 9
−
−
−10
−
−
mV/K
mV/K
∆Vo(c)(T)(offset) differential output offset
voltage temperature drift
between pins 7 and 8,
0
8 and 9 and 7 and 9
Io(m)(offset)
offset current of measurement Io(c) = 0 µA;
−50
0.9
−
−
+50
1.1
−
µA
output
1.5 V < Vi < 5.5 V;
3 V < Vo(m) < 6 V
∆Io(m)/∆Io(c)
linearity of current transfer
−100 µA < Io(c) < 100 µA;
1.5 V < Vi < 5.5 V;
1.0
1.0
3 V < Vo(m) < 6 V
at CRT discharge;
Io(c) = 1 mA;
1.5 V < Vi < 5.5 V;
3 V < Vo(m) < 5.4 V
Io(c)(max)
Vo(c)(min)
Vo(c)(max)
BS
maximum peak output current 50 V < Vo(c) < VDD − 50 V
(pins 7, 8 and 9)
−
−
20
−
mA
V
minimum output voltage
(pins 7, 8 and 9)
Vi = 7.0 V; note 1
Vi = 1.0 V; note 1
Vo(c) = 60 V (p-p)
Vo(c) = 100 V (p-p)
−
10
−
maximum output voltage
(pins 7, 8 and 9)
V
−
−
DD − 15 −
V
small signal bandwidth
(pins 7, 8 and 9)
5.5
4.5
−
MHz
MHz
BL
large signal bandwidth
(pins 7, 8 and 9)
−
1999 Oct 26
5
