Philips Semiconductors
Product specification
Class AB stereo headphone driver
TDA1308
LIMITING VALUES
In accordance with the Absolute Maximum Rating System (IEC134).
SYMBOL
VDD
tSC(O)
Tstg
PARAMETER
supply voltage
CONDITIONS
MIN.
MAX.
8.0
UNIT
0
V
output short-circuit duration
storage temperature
Tamb = 25 °C; Ptot = 1 W
20
−
s
−65
+150
+85
°C
°C
V
Tamb
Vesd
operating ambient temperature
electrostatic discharge
−40
note 1
note 2
−2000
−200
+2000
+200
V
Notes
1. Human body model: C = 100 pF; R = 1500 Ω; 3 pulses positive plus 3 pulses negative.
2. Machine model: C = 200 pF: L = 0.5 mH: R = 0 Ω; 3 pulses positive plus 3 pulses negative.
THERMAL CHARACTERISTICS
SYMBOL
Rth j-a
PARAMETER
VALUE
UNIT
thermal resistance from junction to ambient in free air
DIP8
SO8
109
210
K/W
K/W
QUALITY SPECIFICATION
In accordance with “UZW-BO/FQ-0601”. The numbers of the quality specification can be found in the “Quality Reference
Handbook”. The handbook can be ordered using the code 9398 510 63011.
August 1994
5
