Absolute Maximum Ratings
Stresses exceeding the absolute maximum ratings may damage the device. The device may not function or be
operable above the recommended operating conditions and stressing the parts to these levels is not recommended.
In addition, extended exposure to stresses above the recommended operating conditions may affect device reliability.
The absolute maximum ratings are stress ratings only.
Symbol
VCC
Parameter
Min.
-0.3
-0.3
Max.
6.0
Unit
V
DC Supply Voltage
VIO
Analog and Digital I/O
VCC+0.3
50
V
VOUT
Maximum Output Current, Do Not Exceed
mA
Electrostatic Discharge Information
Symbol
Parameter
Min
9
Unit
Human Body Model, JESD22-A114
Charged Device Model, JESD22-C101
ESD
kV
2
Reliability Information
Symbol
Parameter
Min.
Typ.
Max.
+150
+150
+300
Unit
°C
TJ
TSTG
TL
Junction Temperature
Storage Temperature Range
-65
°C
Lead Temperature (Soldering, 10 Seconds)
°C
Thermal Resistance, JEDEC Standard,
Multilayer Test Boards, Still Air
90
°C/W
JA
Recommended Operating Conditions
The Recommended Operating Conditions table defines the conditions for actual device operation. Recommended
operating conditions are specified to ensure optimal performance to the datasheet specifications. Fairchild does not
recommend exceeding them or designing to Absolute Maximum Ratings.
Symbol
TA
Parameter
Operating Temperature Range
Supply Voltage Range
Min.
-40
Typ.
Max.
+85
Unit
°C
VCC
3.14
3.30
5.25
V
© 2009 Fairchild Semiconductor Corporation
FMS6144A • Rev. 1.0.2
www.fairchildsemi.com
