WL/WLM
Spatter-prevention Switches
Ratings
Characteristics
Degree of protection
Screw terminals
IP67
Item
Non-inductive load (A)
Inductive load (A)
Mechanical
Electrical
15,000,000 operations min. *2
750,000 operations min. *3
1 mm/s to 1 m/s (in case of WLCA2)
120 operations/minute min.
30 operations/minute min.
50/60 Hz
Durability
*1
Rated
voltage (V)
Resistive
load
Lamp
load
Inductive
load
Motor
load
Operating speed
Model
NC NO NC NO NC NO NC NO
Mechanical
Electrical
Operating
frequency
125 VAC
250 VAC
10
10
3
2
1.5
1
10
10
5
3
2.5
1.5
WL@-LES
115 VAC
10
3
1.5
10
5
2.5
Rated frequency
12 VDC
24 VDC
48 VDC
10
6
3
6
4
2
3
3
1.5
10
6
3
6
4
2
Insulation resistance
100 MΩ min. (at 500 VDC)
25 mΩ max. (initial value for the built-
in switch when tested alone)
WL@-LDS
Contact resistance
Between
Note: 1. The above figures are for steady-state currents.
2. Inductive loads have a power factor of 0.4 min. (AC) and a time
constant of 7 ms max. (DC).
3. A lamp load has an inrush current of 10 times the steady-state current.
4. A motor load has an inrush current of 6 times the steady-state current.
terminals of 1,000 VAC (600 VAC), 50/60 Hz for
the same
polarity
1 min
Between
current-
NC
NO
30 A max.
20 A max.
Inrush
2,200 VAC (1,500 VAC), 50/60 Hz for
1 min/Uimp 2.5 kV
carrying
current
Dielectric
strength
metal part
and ground
Between
each
Operating temperature –10°C to +80°C (with no icing)
Operating humidity 35% to 95%RH max.
terminal and 2,200 VAC (1,500 VAC), 50/60 Hz for
Approved Standard Ratings
non-current- 1 min/Uimp 2.5 kV
carrying
metal part
UL/CSA
LE Switches (Neon lamp): A300
Rated insulation voltage
(Ui)
Current (A)
Volt-amperes (VA)
Rated
Carry
250 V (EN60947-5-1)
3 (EN60947-5-1)
voltage
current
Make
Break
Make
Break
Pollution degree
(operating environment)
Short-circuit protective
device (SCPD)
120 VAC
240 VAC
60
30
6
3
10 A
7,200
720
10 A, fuse type gG or gI (IEC60269)
100 A (EN60947-5-1)
10 A, 0.5 A (EN60947-5-1)
Class I
LD Switches (LED)
Conditional short-circuit
current
Rated voltage
115 VAC
Carry current
10 A
Conventional enclosed
thermal current (Ithe)
Protection against
electric shock
115 VDC
0.8 A
CCC (GB14048.5)
Vibration
Model
Application category and ratings
AC-15: 2 A/250 V
DC-12: 2 A/48 V
Malfunction 10 to 55 Hz, 1.5-mm double amplitude
resistance
1,000 m/s2 min.
WL@
Destruction
Malfunction 300 m/s2 min.
Shock
resistance
AC-14: 0.1 A/125V
DC-12: 0.1 A/48 V
WL01@
Ambient operating
temperature
–10°C to +80°C (with no icing)
WL@-LE
WL01@-LE
AC-15: 2 A/250 V
Ambient operating
humidity
Weight
AC-14: 0.1 A/125 V
35% to 95%RH
AC-15: 2 A/115 V
DC-12: 2 A/48 V
WL@-LD
Approx. 275 g (in case of WLCA2)
Note: 1. The above figures are initial values.
AC-14: 0.1 A/115 V
DC-12: 0.1 A/48 V
WL01@-LD
2. The figures in parentheses for dielectric strength are those for the high-
sensitivity overtravel models.
*1. The values are calculated at an operating temperature of +5°C to +35°C and
an operating humidity of 40% to 70%RH. Contact your OMRON sales
representative for more detailed information on other operating
environments.
Note: As an example, AC-15: 2 A/250 V means the following:
Application category
AC-15
*2. Durability is 10,000,000 operations min. for general-purpose or high-
sensitivity overtravel models.
*3. Durability is 500,000 operations min. for high-precision models. All
microload models however, are 1,000,000 operations min.
Rated operating current (Ie) 2 A
Rated operating voltage (Ue) 250 V
21
