New H7EC
Dimensions
Note: All units are in millimeters unless otherwise indicated.
H7EC-N
M3.5 terminal screw
Panel Cutout
Separate mounting
40 min.
45+0.5
0
22.2+0.5
0
Dimensions with Y92F-34 Flush Mounting Bracket
Dense mounting
+1.0
0
(48 Units − 2.5)
22.2+0.5
0
Waterproofing is not possible for
dense mounting
•
When mounting, insert the Counter into
the cutout, insert the adapter from the
back and push in the Counter while
making the gap between the front panel
and the cutout panel as small as
possible. Use screws to secure the
Counter. If waterproofing is desired,
insert the waterproof packing.
•
•
When several Counters are installed,
ensure that the ambient temperature
will not exceed specifications.
The appropriate thickness of the panel
is 1 to 5 mm.
Note: A Compact Flush Mounting Bracket (Y92F-35) can also be used. Refer to Accessories for details.
