J DEDICATED I/O MODULES
Stock Note: Shaded models are normally stocked.
Item
Specifications
International
standards
Part number
Analog I/O modules
Analog inputs: 4 points, built-in power supply
U, C, N, CE
U, C, N, CE
U, C, N, CE
CQM1-AD042
CQM1-AD041
CQM1-DA022
CQM1-DA021
CQM1-IPS01
Analog inputs: 4 points, order separate power supply
Analog outputs: 2 points, built-in power supply
Analog outputs: 2 points, order separate power supply
Power Supply Module re-
quired for AD041 and DA021
modules
For one Analog module
For two Analog modules
CQM1-IPS02
B7A Master link modules*
16 outputs
—
CQM1-B7A02
CQM1-B7A12
CQM1-B7A03
CQM1-B7A13
CQM1-B7A21
CQM1-TC001
CQM1-TC002
CQM1-TC101
U, C
16 inputs
32 outputs
32 inputs
16 inputs and 16 outputs
—
Temperature controller
modules
Thermocouple input, transistor (NPN) output, 2 loops
Thermocouple input, transistor (PNP) output, 2 loops
U, C, CE
Platinum resistance thermometer input, transistor (NPN)
output, 2 loops
Platinum resistance thermometer input, transistor (PNP)
output, 2 loops
CQM1-TC102
Temperature controller
modules (continued)
U, C, CE
Thermocouple input, transistor (NPN) output, 4 loops
Thermocouple input, transistor (PNP) output, 4 loops
CQM1-TC201
CQM1-TC202
CQM1-TC203
Thermocouple input, transistor (NPN) output, 2 loops
(with heater burnout alarm)
Thermocouple input, transistor (PNP) output, 2 loops
(with heater burnout alarm)
CQM1-TC204
CQM1-TC301
CQM1-TC302
CQM1-TC303
CQM1-TC304
Platinum resistance thermometer input, transistor (NPN)
output, 4 loops
Platinum resistance thermometer input, transistor (PNP)
output, 4 loops
Platinum resistance thermometer input, transistor (NPN)
output, 2 loops (with heater burnout alarm)
Platinum resistance thermometer input, transistor (PNP)
output, 2 loops (with heater burnout alarm)
Linear sensor interface
modules
—
Standard
CQM1-LSE01
CQM1-LSE02
CQM1-SF200
With monitor output
Safety relay module
Emergency stop unit: 2 inputs/2 outputs, 4 general-
purpose inputs
U, C
Note: U: UL, C: CSA, N: NK, L: LLOYD, CE: EC Directives
*B7A Slave Link Modules are listed in the Dedicated I/O Modules section describing B7A Master Link Modules.
