TJA1055
NXP Semiconductors
Enhanced fault-tolerant CAN transceiver
maximum peak temperature
= MSL limit, damage level
temperature
minimum peak temperature
= minimum soldering temperature
peak
temperature
time
001aac844
MSL: Moisture Sensitivity Level
Fig 12. Temperature profiles for large and small components
For further information on temperature profiles, refer to Application Note AN10365
“Surface mount reflow soldering description”.
15. Appendix
15.1 Overview of differences between the TJA1055 and the TJA1054A
Table 12. Limiting values
Symbol
Parameter
Conditions
TJA1055
TJA1054A
Unit
Min
−58
−58
Max
Min
−27
−27
Max
VCANH
VCANL
Vesd
voltage on pin CANH
voltage on pin CANL
+58
+58
+40
+40
V
V
electrostatic discharge voltage pins RTH, RTL, CANH, CANL
human body model
IEC 61000-4-2
−8
+8
−4
+4
kV
[1]
[1] The ESD performance of pins CANH, CANL, RTH and RTL, with respect to GND, was verified by an external test house in accordance
with IEC-61000-4-2 (C = 150 pF, R = 330 Ω). The results were equal to, or better than, ±6 kV for TJA1055 and equal to, or better than,
±1.5 kV for TJA1054A.
TJA1055_4
© NXP B.V. 2009. All rights reserved.
Product data sheet
Rev. 04 — 17 February 2009
23 of 26
