M29FxxxFT, M29FxxxFB
Description
Figure 12. Block Addresses, M29F800 (x8)
Top Boot Block Addresses(x8)
Bot t om Boot Block Addresses (x8)
FFFFFh
FFFFFh
16 KByte
8 KByt e
8 KByt e
32 KByte
64 KByte
64 KByte
64 KByte
FC000h
FBFFFh
F0000h
EFFFFh
FA000h
F9FFFh
E0000h
Tot al of 15
64 KByt e Blocks
F8000h
F7FFFh
F0000h
EFFFFh
1FFFFh
64 KByte
32 KByte
8 KByt e
8 KByt e
16 KByte
E0000h
10000h
0FFFFh
08000h
07FFFh
Tot al of 15
64 KByt e Blocks
06000h
05FFFh
1FFFFh
64 KByte
64 KByte
10000h
0FFFFh
04000h
03FFFh
00000h
00000h
AI05463_x8_800
Also see Appendix Appendix A: Block Address Table for a full listing of the Block Addresses.
Figure 13. Block Addresses, M29F800 (x16)
Top Boot Block Addresses(x16)
Bot t om Boot Block Addresses (x16)
7FFFFh
7FFFFh
8 KWord
4 KWord
4 KWord
16 KWord
32 KWord
32 KWord
32 KWord
7E000h
7DFFFh
78000h
77FFFh
7D000h
7CFFFh
70000h
Tot al of 15
32 KWord Blocks
7C000h
7BFFFh
78000h
77FFFh
0FFFFh
32 KWord
16 KWord
4 KWord
4 KWord
8 KWord
70000h
08000h
07FFFh
04000h
03FFFh
Tot al of 15
32 KWord Blocks
03000h
02FFFh
0FFFFh
32 KWord
32 KWord
08000h
07FFFh
02000h
01FFFh
00000h
00000h
AI05464_x16_800
Also see Appendix Appendix A: Block Address Table for a full listing of the Block Addresses.
17/67
