ESD Rating (Note 8)
Junction Temperature
Thermal Resistance
ꢁθJA (SO)
Soldering Information
Infrared or Convection (20 sec)
1000V
150°C
Absolute Maximum Ratings (Note 1)
If Military/Aerospace specified devices are required,
please contact the National Semiconductor Sales Office/
Distributors for availability and specifications.
145°C/W
260°C
Power Supply Voltage
(VS = V+ - V-)
38V
−65°C to 150°C
(V-) - 0.3V to (V+) + 0.3V
Continuous
Storage Temperature
Input Voltage
Output Short Circuit (Note 3)
Power Dissipation
ESD Rating (Note 4)
ESD Rating (Note 5)
Operating Ratings (Note 1)
Temperature Range
Internally Limited
2000V
TMIN ≤ TA ≤ TMAX
Supply Voltage Range
–40°C ≤ TA ≤ 85°C
±5V ≤ VS ≤ ±18V
200V
Electrical Characteristics (Note 2)
The following specifications apply for VS = ±15V, RL = 2kΩ, fIN = 1kHz, and TA = 25°C, unless otherwise specified.
LME49990
Units
(Limits)
Symbol
Parameter
Conditions
Typical
Limit
(Note 6)
(Note 7)
POWER SUPPLY
±5
±18
V (min)
V (max)
VCC
Operating Supply Voltage
VCM = 0V, VO = 0V, IO = 0mA
VCC = ±5V
8
9
9
10
11
12
ICCQ
Quiescent Current
mA (max)
VCC = ±15V
VCC = ±18V
VCC = ±5V to ±18V
TMIN−TMAX
144
137
119
116
dB (min)
dB (min)
PSRR
Power Supply Rejection Ratio
DYNAMIC PERFORMANCE
AV = 1, VO = 3VRMS, RL= 1kΩ
f = 1kHz
f = 20kHz
THD+N
Total Harmonic Distortion + Noise
0.00002
0.00001
0.00003
% (max)
%
AV = 1, VO = 3VRMS
IMD
Intermodulation Distortion
Two-tone 60Hz & 7kHz 4:1
0.000017
110
%
GBWP
FPBW
Gain Bandwith Product
Full Power Bandwidth
AV = 104, RL = 2kΩ, f = 90kHz
MHz
AV = –1, VO = 20VPP, RL = 1kΩ
AV = –1, VO = 20VPP
RL = 1kΩ
291
kHz
V/μs (min)
ns
SR
ts
Slew Rate
22
16.5
AV = –1, VO = 10VPP, RL = 1kΩ
0.01%
Settling time
590
VO = ±10V
135
124
120
120
dB (min)
dB
RL = 2kΩ
TMIN – TMAX
AVOL
Open-Loop Gain
130
122
dB (min)
dB
RL = 600Ω
TMIN – TMAX
3
