Low-Cost, Selectable-Voltage, Digital I/O Devices up to 50 MHz
Trigger detection................................. Start trigger (edge detection:
Compliance
Safety
rising or falling; pattern match:
match or don’t match)
Pause trigger (level detection:
high or low; pattern match:
match or don’t match)
Reference trigger (edge detection:
rising or falling; pattern match:
match or don’t match)
The NI 6535/36/37 devices meet the requirements of the following
standards for safety and electrical equipment for measurement,
control, and laboratory use:
• IEC 61010-1, EN 61010-1
• UL 3111-1, UL 61010-1
• CSA 61010-1
Note: For full EMC compliance, you must operate this device with
shielded cabling. In addition, all covers and filler panels must be
installed. Refer to the Declaration of Conformity (DoC) for this product
for any additional regulatory compliance information.
Handshaking trigger
(interlocked: high or low)
Destinations........................................ PFI <0:5> (DDC connector)
RTSI <0:7> (PCI Express only)
PXI_TRIG<0:7>
For access to certifications, marks, and DoCs, visit
(PXI Express only)
DSTARC (PXI Express only)
ni.com/certification.
Events (outputs from NI 6536/37)
Event types.......................................... Data active, ready for start,
ready for transfer, handshaking,
change detection
Destinations........................................ PFI <0:5> (DDC connector)
RTSI <0:7> (PCI Express only)
Ordering Information
PXI_TRIG<0:7>
(PXI Express only)
DSTARC (PXI Express only)
NI PCIe-6535..........................................................................780694-01
NI PXIe-6535..........................................................................780695-01
NI PCIe-6536..........................................................................779672-01
NI PXIe-6536..........................................................................779988-01
NI PCIe-6537..........................................................................779673-01
Miscellaneous
Physical
Dimensions
NI PXIe-6537..........................................................................779989-01
Includes NI-DAQmx software.
PCI Express ..................................... 18.1 by 12.6 cm (7.13 by 4.93 in.)
PXI Express ..................................... 21.4 by 13.1 cm (8.42 by 5.14 in.)
Software
NI Digital Waveform Editor ..................................................778724-03
Power Requirements
Typical ................................................. 5.1 W
Maximum ............................................ 6.1 W
Cables
SHC68-C68-D4 Shielded Single-Ended Cable ......................196275-01
C68-C68-D4 (unshielded 1 m cable)......................................195949-01
SHC68-H1X38 (flying lead 1.5 m cable)..............................192681-1R5
Software
Driver and application software......... NI-DAQmx
Environment
Terminal Blocks
Operating temperature
CB-2162 (terminal block with pin headers) ..........................778592-01
SMB-2163 (SMB breakout box) ............................................778747-01
Header Jumper Kit ................................................................199101-01
PCI Express ..................................... 0 to +45 °C
PXI Express ..................................... 0 to +55 °C
Storage temperature........................... -20 to +70 °C
Operating relative humidity................ 10 to 90%, noncondensing
(meets IEC-60068-2-56)
Connectors
Dual Stacked VHDCI Connector, 68-Pin, Right-Angle ..........780390-01
VHDCI Connector, 68-Pin, Vertical ........................................780389-01
VHDCI Connector, 68-Pin, Right-Angle..................................778914-01
NI 653x Cable Adapter (68-pin SCSI to 68-pin VHDCI) ........195846-01
Storage relative humidity ................... 5 to 95%, noncondensing
(meets IEC-60068-2-56)
