Nexperia
PMEG120G20ELR
120 V, 2 A Silicon Germanium (SiGe) rectifier
t
t
1
2
P
duty cycle δ =
t
2
t
1
t
006aaa812
Fig. 17. Duty cycle definition
The current ratings for the typical waveforms are calculated according to the equations:
IF(AV)=IM×δ with IM defined as peak current
IRMS=IF(AV) at DC, and IRMS=IM×√δ
with IRMS defined as RMS current.
Quality information
This product has been qualified in accordance with the Automotive Electronics Council (AEC)
standard Q101 - Stress test qualification for discrete semiconductors, and is suitable for use in
automotive applications.
12. Package outline
1.9
1.5
1.1
0.9
1
0.6
0.3
3.7 2.8
3.3 2.4
2
1.05
0.75
0.22
0.10
Dimensions in mm
08-11-06
Fig. 18. Package outline CFP3 (SOD123W)
©
PMEG120G20ELR
All information provided in this document is subject to legal disclaimers.
Nexperia B.V. 2020. All rights reserved
Product data sheet
28 February 2020
9 / 14
